There has been a lot of advancement taken place in few years and with it, new and different grades of Stainless Steel 316 Forged Fittings are available in the market. But, the thing that hits every mind is why these forged fittings are popular. If you also have this question then the answer is their high tensile strength, corrosion resistance, and durability. Well, if you are in search of a reputed and prominent manufacturer then Lanco pipe and fitting is the right option available in front of you. They can provide you excellent quality and size of fittings as per your requirement and order.
Well, if we talk about forged fittings specification they cover both national and international standards and specification including ASTM A182 & ASME SA182. The size of these forged fittings varies from 1/8 NB to 4 NB and available types are socket weld and screwed threaded forged fittings. Furthermore, these forged fittings are divided into different classes such as 2000 LBS, 3000 LBS, and 9000 LBS. these forged fittings are used in several high-pressure applications including chemical equipment, gas processing, seawater equipment and petrochemicals.
These Stainless Steel 316 Forged Fittings come across various tests and inspection done by the quality experts and inspection agencies who in turn offer various test certificates like raw material certificate, EN test certificate, radiography test certificate and third-party inspection report. Furthermore, to prevent these forged fittings from damage and rust they are packed in wooden cases and poly bags with a proper marking of company’s name, product name, size as well as length.
Specifications : ASTM / ASME A182 / SA182
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799.
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class/Pressure : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | - | Z7CND17-11-02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Element | SS 316 |
C | 0.08 max |
Mn | 2 max |
Si | 1 max |
P | 0.045 max |
S | 0.030 max |
Cr | 16 - 18 |
Ni | 11 - 14 |
Mo | 2 - 3 |
N | 67.845 min |
Element | SS 316 |
Density | 8.0 g/cm3 |
Melting Point | 1399 °C (2550 °F) |
Tensile Strength | Psi – 75000 , MPa – 515 |
Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
Elongation | 35 % |
Stainless Steel 316 Forged Fittings uses in Food Processing Industry |
Stainless Steel 316 Socketweld Fittings uses in Fabrication Industry |
Stainless Steel 316 Forged Fittings uses in Oil and Gas Industry |
UNS S31600 SS Forged Threaded Elbow uses in Chemical Industry |
Grade 316 Stainless Steel Forged Fittings uses in Plumbing |
316 SS Screwed Fittings uses in General Purpose Applications |
Stainless Steel 316 Socketweld Equal Tee uses in Heating |
SS 316 Screwed Unequal Cross uses in Water Supply Systems |
ASTM A182 316 Steel Forged Fittings uses in Power Plant |
SS 316 Socketweld Fittings uses in Paper & Pulp Industry |
SS 316 Threaded Fittings uses in Defence Industry |
SS 316 Forged Union uses in Construction industry |
