| Steel 304L Socket Weld Tee |
| SS 304L Socket Weld Cross |
| SS S30403 Forged Coupling |
| SS 304L Forged 90 Deg Elbow |
| SS 304L Forged 45 Deg Elbow |
| SS 304L Forged Cap Exporter |
| SS 304L Austenitic Steel End Cap |
| SS 304L Screwed Pipe Nipple |
| SS 304L Threaded Hex Plug |
| SS 304L Screwed Street Elbow |
| SS 304L Threaded Union Stockist |
| SS 304L Threaded Bushing |
Are you in search of best quality of stainless steel Forged Pipe fittings and searching for the best manufacturing company? If yes, then your search ends here as Lanco pipe and fittings are one of the esteemed companies that manufacture Stainless Steel 304L Forged Fittings of best quality and grade. This company offers its clients and customers pipe fittings at an affordable rate and with quality approval certificate. Moreover, they manufacture these pipe fittings with premium quality of raw material that is well tested and inspected and approved as per international and national standards. Well, if you are in need to know about forged fittings specifications, then continue reading this article and know about it.
These forged fittings are available in different types such as socket weld fittings and threaded fittings and as per customers request and requirements. These forged fittings are available in different sizes that range from ½ NB to 48 NB and covered dimensions are ASME B16.11 and BS3799. Moreover, the wall thickness of these fittings is divided into various sections like SCH 5S, 10S, 60S XXS and custom thickness. These fittings cover ASTM A182, ASME SA182 designation.
Well, if we talk about its packaging and certification, these Stainless Steel 304L Forged Fittings are certificated after complete examination and inspection which is done under the supervision of quality experts and inspection agencies. Furthermore, when these fittings are ready for the delivery they are packed in wooden boxes or cases and with proper marking about companies’ name, size, and length etc so as to prevent rusting.
Stainless Steel 304L Forged Fittings Specification
Specifications : ASTM / ASME A182 / SA182
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799.
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class/Pressure : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
B16.11 Stainless Steel 304L Forged Fittings Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304L | 1.4306 / 1.4307 | S30403 | SUS 304L | 3304S11 | 03Х18Н11 | Z3CN18-10 | X2CrNi18-9 / X2CrNi19-11 |
ASTM A182 SS 304L Forged Fittings Chemical Composition
| Element | SS 304L |
| C | 0.035 max |
| Mn | 2 max |
| Si | 1.0 max |
| P | 0.045 max |
| S | 0.03 max |
| Cr | 18 – 20 |
| Ni | 8 – 13 |
Stainless Steel S30403 Forged Fittings Mechanical & Physical Properties
| Element | SS 304L |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
Stainless Steel 304L Forged Fittings Application
| Stainless Steel 304L Forged Fittings uses in Food Processing Industry |
| Stainless Steel 304L Socketweld Fittings uses in Fabrication Industry |
| Stainless Steel 304L Forged Fittings uses in Oil and Gas Industry |
| UNS S30403 SS Forged Threaded Elbow uses in Chemical Industry |
| Grade 304L Stainless Steel Forged Fittings uses in Plumbing |
| 304L SS Screwed Fittings uses in General Purpose Applications |
| Stainless Steel 304L Socketweld Equal Tee uses in Heating |
| SS 304L Screwed Unequal Cross uses in Water Supply Systems |
| ASTM A182 304L Steel Forged Fittings uses in Power Plant |
| SS 304L Socketweld Fittings uses in Paper & Pulp Industry |
| SS 304L Threaded Fittings uses in Defence Industry |
| SS 304L Forged Union uses in Construction industry |
