We Lanco pipe and fittings are manufacturers, exporters, and suppliers of Inconel 600 flanges all across the globe. These grade flanges are highly appreciated by the buyers into the global market just because of features like superior quality, durability and non-magnetic. The flanges are confirming to stringent international standard. The flanges are used widely in various applications like spray bars, seawater application, gas turbine line etc. These flanges are easily available on both online stores as well as in the market stores.
The dimensions of Inconel 600 flanges are ANSI B16.5, ASA, ANSI B16.47 A and B series, MSS SP 44, AWWA and in custom drawings. The standard specification of flanges is BS flanges, ANSI flanges, ASTM flanges, ASME flanges, DIN flanges and EN flanges. The specification of the flange is ASME SB 564 and ASTM B 564. In size, it is available as ½” to 36”. The classes of flanges are PN64, 150#, PN6, 300#, PN40, 600#, PN10, 2500#, PN25, 900#, and 1500#. The grade of flanges is Inconel 600- UNS N) 6600. The flange is conforming NACE MR0175/ISO 15156.
Packaging factor is well considerable factor in every industry that is dealing in producing and supplying of Inconel 600 flanges. Also, the industry understands very well that how important is high quality of product packing is for the buyers. The packaging of the flange is done using a standard technique. It is as the ordered product has to pass through different channels. For it, protection packing has become mandate. Flanges are packed using wooden crates, wooden boxes, and carton. This helps in protecting those from getting damages or scratches on its surface. Also, the packing is done as per the client requests. This thus ensures buyers that their consignment will be delivered with full safety.
Inconel 600 Flanges Specification
Specifications : ASTM / ASME B564 / SB564
Dimensions : ANSI B 16.5, BS 1560. BS 10, IS 6392, B-2.1 NPT, API, DIN, JIS. MSS SP 44
Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size : ½” NB to 12” NB
Class/Pressure : 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS , ASA 150#, ASA 300# DIN ND 6,10,16,25,40 Etc
Inconel 600 Flanges Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Alloy 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
ASTM B564 Inconel Alloy 600 Flanges Chemical Composition
| Element | Alloy 600 |
| C | 0.15 max |
| Mn | 1.00 max |
| Si | 0.50 max |
| Cu | 0.50 max |
| S | 0.015max |
| Cr | 14.00 – 17.00 |
| Ni | 72.00 min |
Inconel N06600 Flanges Mechanical & Physical Properties
| Element | Alloy 600 |
| Density | 8.47 g/cm3 |
| Melting Point | 1413 °C (2580 °F) |
| Tensile Strength | Psi – 95,000 , MPa – 655 |
| Yield Strength (0.2%Offset) | Psi – 45,000 , MPa – 310 |
| Elongation | 40 % |
Inconel 600 Flanges Application
| Inconel 600 Flanges uses in Food Processing Industry |
| Inconel Flanges uses in Fabrication Industry |
| Inconel 600 Flanges uses in Oil and Gas Industry |
| N06600 Inconel Slip on Flanges uses in Chemical Industry |
| Grade 600 Inconel Flanges uses in Plumbing |
| 600 Inconel Flanges uses in General Purpose Applications |
| Inconel 600 Blind Flanges uses in Heating |
| Inconel Alloy 600 Orifice Flanges uses in Water Supply Systems |
| ASTM B564 Inconel Flanges uses in Power Plant |
| Inconel Alloy 600 Forged Flanges uses in Paper & Pulp Industry |
| Inconel Alloy 600 Threaded Flanges uses in Defence Industry |
| Inconel Alloy 600 Loose Flanges uses in Construction industry |
