Duplex Steel UNS S32205/S31803 Pipe Fittings this is known to be the most widely used stainless steel grade that contains all best features. It has best corrosion resistance property and with that carries great strength. This is used by several known industries because they know its features make it reliable for long. You don’t need to change the fittings again and again that you use to do when you were using the old normal types of fittings. This product is mainly suitable for the temperature which not exceeds 300 degree Celsius. Beside this, it carries the microstructure which lies between the 40-50 percent ferrite. It is widely used in many processing equipment.
Talking about is corrosion resistance property then it works well in any type of environment. With that, it also includes the crevice, intergranular and pitting corrosion. These fittings are now mainly used in the seawater. Even in seawater, it doesn’t get damaged. It polishes and varnish protects it from several attacks of the environment.
In last when you look into it packing section you will see that at the time of packing the workers take great care. They firstly cover the fittings with the plastic and after that keep in the boxes. These boxes are of wooden or of other metal. These whole processes are done just to protect sides of the fittings because in case they get damaged it will not fit with the pipe in the right way. So, at the time of buying Duplex Steel UNS S32205/S31803 Pipe Fittings look all the sides of it’s careful.
Duplex Steel S31803 / S32205 Buttweld Fittings Specification
Specifications : ASTM A815 / ASME SA815
Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Type : Seamless / Welded / Fabricated
Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
S31803 / S32205 Duplex Steel Buttweld Fitting Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS |
| Duplex Steel | 1.4462 | S31803 / S32205 |
ASTM A815 Duplex Steel S31803 / S32205 Buttweld Fitting Chemical Composition
| Element | S31803 | S32205 |
| C | 0.03 max | 0.03 max |
| Mn | 2 max | 2 max |
| Si | 1 max | 1 max |
| P | 0.03 max | 0.03 max |
| S | 0.02 max | 0.02 max |
| Cr | 22 – 23 | 21 – 23 |
| Mo | 3.0 – 3.5 | 2.5 - 3.5 |
| Ni | 4.5 – 6.5 | 4.5 – 6.5 |
| N | 0.14 – 0.20 | 0.8 – 0.20 |
| Fe | 63.72 min | 63.54 min |
Duplex Steel UNS S31803 / S32205 Pipe Fittings Mechanical & Physical Properties
| Element | Duplex Steel |
| Density | 7.8 g/cm3 |
| Melting Point | 1350 °C (2460 °F) |
| Tensile Strength | Psi – 80000 , MPa – 550 |
| Yield Strength (0.2%Offset) | Psi – 116000 , MPa – 800 |
| Elongation | 15 % |
Duplex Steel S31803 / S32205 Pipe Fittings Application
| Duplex Steel S31803 Pipe Fittings uses in Food Processing Industry |
| Duplex Steel Welded S32205 Fitting uses in Fabrication Industry |
| Duplex Steel S31803 Buttweld Fittings uses in Oil and Gas Industry |
| S32205 Duplex Steel Buttweld Elbow uses in Chemical Industry |
| UNS S31803 Duplex Steel Pipe Elbow uses in Plumbing |
| Duplex Steel S32205 End Cap uses in General Purpose Applications |
| Duplex Steel S31803 Pipe Nipple uses in Heating |
| Duplex S32205 Eccentric Reducer uses in Water Supply Systems |
| ASTM A815 S31803 Seamless Buttweld Fitting uses in Power Plant |
| Duplex UNS S32205 45° Elbow uses in Paper & Pulp Industry |
| Duplex Steel S31803 Short Radius Elbow uses in Defence Industry |
| Duplex S32205 Long Radius Elbow uses in Construction industry |
