Available Forms of Nickel Alloy Sheet Plate and Coils

Nickel Sheet Plate and Coils Specification

Standard : ASTM / ASME B162 / SB162

Size : 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm

Thickness : 0.1mm to 12 mm Thk

Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)

Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)

Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.

Nickel Sheet Plate and Coils Equivalent Grades

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Nickel 200 2.4066 N02200 NW 2200 NA 11 НП-2 N-100M Ni 99.2
Nickel 201 2.4068 N02201 NW 2201 NA 12 НП-2 - LC-Ni 99

ASTM B162 Nickel Alloy Sheet Plate and Coils Chemical Composition

Element Nickel 200 Nickel 201
C 0.15 max 0.02 max
Mn 0.35 max 0.35 max
Si 0.35 max 0.35 max
S 0.01 max 0.01 max
Cu 0.25 max 0.25 max
Fe 0.40 max 0.40 max
Ni 99.0 min 99.0 min

Nickel N02200 Sheet Plate and Coils Mechanical & Physical Properties

Element Nickel
Density 8.9 g/cm3
Melting Point 1446 °C (2635 °F)
Tensile Strength Psi – 67000 , MPa – 462
Yield Strength (0.2%Offset) Psi – 21500 , MPa – 148
Elongation 45 %

Nickel Sheet Plate and Coils Application

Nickel Sheet Plate and Coils in various Application Industries
  Nickel Sheets uses in Food Processing Industry
  Nickel Plate uses in Fabrication Industry
  Nickel 200 Sheet uses in Oil and Gas Industry
  UNS N02200 Nickel Shim Sheet uses in Chemical Industry
  Grade 201 Nickel Alloy Sheet & Plate uses in Plumbing
  201 Nickel Foils uses in General Purpose Applications
  Nickel Alloy HR Plates uses in Heating
  Nickel Hot Rolled Plates uses in Water Supply Systems
  ASTM B162 Nickel Alloy Coils uses in Power Plant
  Nickel Cold Rolled Plates uses in Paper & Pulp Industry
  Nickel Alloy Circle uses in Defence Industry
  Nickel Profile uses in Construction industry
