| Nickel Forged 90 Deg Elbow |
| Nickel Forged 45 Deg Elbow |
| Nickel Forged Cap Exporter |
| Nickel Socket Weld Tee |
| Nickel Socket Weld Cross |
| UNS N02200 Forged Coupling |
| Nickel Threaded Bushing |
| Nickel Screwed Street Elbow |
| Nickel Alloy Threaded Union |
| Nickel Screwed Pipe Nipple |
| Nickel Threaded Hex Plug |
| Nickel High Tensile End Cap |
The nickel forged fittings are the most demanded and accepted fittings. They are extremely useful in industrial applications. They provide the resistance towards chlorine dioxide in a hypochlorite and in the wet chlorine gas. This represents the high durability of the alloy content. These fittings are made up of alloys consisting of nickel and chromium. They are also having some amount of molybdenum and tungsten. This makes them resistive towards corrosion and they can withstand in any condition including alkali and sea water.
These nickel fittings are having good use in the gas industries also. They can also be used in paper industries and wastewater treatment. These fittings are being testified with the following tests as-
The specifications of Nickel forged fittings
The Lanco pipes are providing a wide range of nickel forged fittings which are having application in all kind of industries. They are providing high-quality metal fittings with very accurate prices.
Nickel Forged Fittings Specification
Specifications : ASTM / ASME B564 / SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799.
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class/Pressure : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
B16.11 Nickel Forged Fittings Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | - | LC-Ni 99 |
ASTM B564 Nickel Alloy Forged Fittings Chemical Composition
| Element | Nickel 200 | Nickel 201 |
| C | 0.15 max | 0.02 max |
| Mn | 0.35 max | 0.35 max |
| Si | 0.35 max | 0.35 max |
| S | 0.01 max | 0.01 max |
| Cu | 0.25 max | 0.25 max |
| Fe | 0.40 max | 0.40 max |
| Ni | 99.0 min | 99.0 min |
Nickel Forged Fittings Mechanical & Physical Properties
| Element | Nickel |
| Density | 8.9 g/cm3 |
| Melting Point | 1446 °C (2635 °F) |
| Tensile Strength | Psi – 67000 , MPa – 462 |
| Yield Strength (0.2%Offset) | Psi – 21500 , MPa – 148 |
| Elongation | 45 % |
Nickel Forged Fittings Application
| Nickel Forged Fittings uses in Food Processing Industry |
| Nickel Socketweld Fittings uses in Fabrication Industry |
| Nickel 200 Forged Fittings uses in Oil and Gas Industry |
| UNS N02200 Nickel Forged Threaded Elbow uses in Chemical Industry |
| Grade 201 Nickel Forged Fittings uses in Plumbing |
| 200 Nickel Screwed Fittings uses in General Purpose Applications |
| Nickel Alloy Socketweld Equal Tee uses in Heating |
| Nickel Alloy Screwed Unequal Cross uses in Water Supply Systems |
| ASTM B564 200 Forged Fittings uses in Power Plant |
| Nickel Alloy Socketweld Fittings uses in Paper & Pulp Industry |
| Nickel Threaded Fittings uses in Defence Industry |
| Nickel Forged Union uses in Construction industry |
